ROLLCLIP Z

4,750.005,210.00

Pulley-carabiner that facilitates installation on anchors and devices

ROLLCLIP Z is a pulley-carabiner with a gate opening on the non-pulley side to facilitate installation on anchors and devices. It is available in two locking systems: automatic TRIACT-LOCK system or manual SCREW-LOCK system.

  • Easier handling:
    – sheave mounted on sealed ball bearings for excellent efficiency
    – gate opening on the non-pulley side, to facilitate installation on devices
    – Keylock system prevents any accidental snagging of the carabiner when putting the pulley in place
  • H cross-section of carabiner:
    – ensures an improved strength-to-weight ratio
    – protects markings from abrasion
  • Two locking systems available:
    – TRIACT-LOCK: automatic locking with triple-action gate opening
    – SCREW-LOCK: the manual screw-lock with red band provides a visual warning when the carabiner is unlocked
LOCKING SYSTEM

SCREW-LOCK, TRIACT-LOCK

Activity

Building Rescue, Flood Rescue, Industry, Intervention, Military, Rescue, Technical Rescue

Brands

Technical Specifications

Material(s): aluminum
Min. rope diameter: 7 mm
Max. rope diameter: 13 mm
Sheave diameter: 18 mm
Maximum working load: 2 x 2 = 4 kN
Efficiency: 85 %
Major axis strength: 20 kN
Minor axis strength: 8 kN
Open gate strength: 7 kN
Guarantee: 3 Years
Inner pack count: 1
