CaRol™ R 150kg winches are rescue winches that have been tested to be attached to one leg of Tracel® tracpode. Compliant with EN 1496 class A, with a maximum load of 150 kg. caRol™ R winch 150kg also meets the requirements of hoisting winches with a maximum load of 250 kg (Directive 2006/42 / EEC)
- Emergency winch.
- Lifting material winch.
- 250 kg capacity for materials handling
- 5 mm galvanised ø cable length available in 20 m and 30 m.
- Conforms to PPE directive EN 1496 150 kg and machine directive 206/42/CEE 250 kg
- Can be used for work in suspension, if you use a second safety fall arrest conforming to EN 360
- NORMS
bracket is conform to the norm EN 795B/2012 for installation on the tracpode.
caRol winch conform to the EN1496/2017class A 150 kg
caRol winch conform to the machine directive 2006/42/CEE
Winch having undergone all breaking and endurance tests according to EN13157:12/2004
Technical Specifications
caRol™ R 150kg winches come with an anchor bracket that attaches to the tracpode legs manufactured by
Tractel®.
They exist in two capacities: 20m and 30m
Drum and gear wheel mounted on bronze bearings.
Double braking safety by self-locking wheel and screw system and use of pawl brake with double spring.
Rigid frame with painted mechanical parts and drum.
Drum disengage able by easily accessible lever with safety device preventing disengagement when carrying a
load.
Users and gears protected by ergonomic cover, removable for maintenance.
Simple, fast cable fastener.
Variable-length control crank handle (6 adjustment positions) allowing user to either apply maximum control
force, or perform rapid cranking for small loads or rewinding.
Self-locking crank handle adjustment knob for maximum user comfort and safety. Allows adjusting crank
handle or removing it to prevent operation of winch.
The caRol ™ R winch 150kg can be secured by 4 points on a vertical mounting plane.
Easily transportable by cross bar.
Console de montage pour tracpode™
